Challenge

A client approached us requiring specialised closed end caps for their containment vessel system. The caps needed to effectively seal external ports when not in use, demanding precise engineering and innovative fabrication techniques. The critical requirements included working with ultra-thin 0.25mm PVC material while incorporating a rubber O-ring for optimal sealing performance.

Technical Complexities

The project presented multiple engineering challenges:

• Achieving consistent welds with exceptionally thin 0.25mm PVC material
• Developing a complex welded profile that maintained structural integrity
• Creating a secure anchoring system for the rubber O-ring without compromising the welding process
• Ensuring 90-degree precision in the O-ring placement for optimal sealing

Solution Development

Our Research & Development team tackled this challenge through innovative tooling design. Leveraging our fluoropolymer manufacturing expertise, our team:

1. Designed and manufactured a custom welding tool in-house specifically for this application
2. Engineered a precise anchoring mechanism that secured both the base material and O-ring during the welding process
3. Developed a specialised welding technique that maintained material integrity while ensuring complete sealing

Results

The innovative approach taken by our R&D team resulted in a highly successful outcome for our client. Through the development of our custom tooling solution, we delivered end caps that achieved perfect sealing integration with the O-ring system while maintaining exceptional weld quality across all production units. The containment vessel's sealing performance met all specifications, and by developing the tooling in-house, we were able to provide our client with a cost-effective solution without compromising on quality or reliability. This project exemplifies our commitment to solving complex engineering challenges through innovative thinking and technical expertise.
